Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: KNTECH
  • Model Number: KNSP-01
  • Color: Yellow
  • Hook: Yes
  • Handset: YES
  • Keypad: YES
  • Button: yes
  • Weatherproof Degree: IP67
  • Lightening Protection Degree: ITU-T K.21
  • Door: Yes
  • Size: 320*205*120mm
  • Cord: Curly Cord

Packaging & Delivery

Packaging Details Industrial ip67 dustproof &waterproof communication system hotline telephone KNSP-01
Machine size:320 *205*120( mm )
Carton size:439 *277 *191( mm )
Packaging material: pearl cotton, carton
Gross weight:7.1KG
Net weight:5.3KG
Delivery Time within 3-18 working days after received payment
Product Description



Industrial ip67 dustproof &waterproof communication system hotline telephone KNSP-01



 Suit for heavy duty usage



Made of industrial environments that need an intercom telephone which can with stand rough usage & treatment.







Specifications



The Weatherproof phone will be designed to work on Railway, metro, tunnel,etc. Housed in robust aluminium die case with spring loaded door, it will offer protection against the outdoor environment,vandals resistance and rot resistance.



The unit will meet all the latest European/UK standards for EMC and US FCC, telephony,

waterproofing IP66, and lightening protection together with offering the level of performance and reliability demanded in such an environment.



 DTMF(Dual Tone Multi Frequency)

Standard and SMART Analogue and VoIP-SIP options available

 Matching with most PABX,PBX and PAX systems.







Main Product Features

1.  Robust aluminium alloy die-cast body

2.  Full keypad with memory, 10 button programmable speed-dial telephone, Illuminated button optional
3.  Door cover: orient automatically and good self - closing, convenient for use.

4.  Weather resistant to IP67 standard, service temperature range from:-30' to +75'C

5.  Magnetic reed hook-switch

6.  Telephone line powered. No external power or battery back up required.

7.  Lightening protection to ITU-T recommendation K.21
8.  Handset: made of special engineering plastic, high anti-knock resistance, Weatherproof, armoured cable optional,

9.  Hearing Aid compatible receiver, Noise canceling microphone.

10.  Handset integrity wiring to enable the telephone system to check if the telephone unit is still operational.

11.  Vandal resistant and tamper-resistant hardware,

12.  Easy installation/ replacement



Packaging specifications
Machine size:320 *205*120( mm )
Carton size:439 *277 *191( mm )
Packaging material: pearl cotton, carton
Gross weight:7.1KG
Net weight:5.3KG


Packaging & Shipping

Kntech standard pearl carton packing.



Company Information









FAQ

Question 1. What version of the phone do you have?
Answer: All of our models are support five versions: analogue(PSTN), VoIP, GSM, PAGA, Wifi. Can be powered by AC110-240V, DC12V / DC5V, telephones line powered, solar, POE, battery or UPS.



Question 2. What's the advantages of your products compared with others?
Answer:
a. Most of our products have got the International Standard certification. Such as IECEx, IP65, IP66, FCC, CCC, ISO9000, EMC, ROHS, SGS, ...etc.
b. We have enough stocks support flexible and fast lead time within 3-7 days.
c. We support the best price lower than others with good quality and 24X7 hours online service. If you could share the project name and the photos of after-installation, we will offer 5-10% discount to support you.

Question 3. How long is the warranty period?
Answer: Normally the warranty period is 18 months after items received. If there any issues on the phones, we can send parts for your replacement.



Question 4. Can you provide a neutral version?
Answer: Yes. we can support neutral version. Normally, the default is our standard Kntech brand and the price is favorable than the neutral version.

Question 5. If some parts of the phones occur issue need to be changed, can we find the parts in our local store?
Answer: Yes, if out of the warranty period, please let us know the issue and we will offer the technical data of the parts and reference price.

Question 6. Can I purchase the accessories separately like PCB board, handset, buttons, speaker, keypad, ...etc?
Answer: Yes, we support MOQ 1pcs.

Question 7. Can I do customized of the products?
Answer: Yes, we support OEM \ ODM order. We have our own R&D Department with high technology support. Please provide your detailed requirements.

Question 8. Can I choose other colors of the phones?
Answer: Yes, normally the default color is yellow. Some model like KNZD-04, KNZD-11, KNZD-13, KNZD-14... support red, blue or white. It is base on our stock. If the quantity over 100pcs, we can support other colors.

Question 9. What's the MTBF of the phone?
Answer: The MTBF is 50,000-70,000 hours. And the average failure rate is very low at 0.3%.
